The Aggregate Shapley I in LMC



Nebulae and stellar associations reside in this complex in the central region of the Large Magellanic Cloud. How much can we see through an amateur telescope?


It is Spring in the Southern Hemisphere, so it is time to aim a telescope to one of our satellite galaxies, the Large Magellanic Cloud (hereafter LMC), and find another interesting structure there. The Magellanic Clouds show a large variety of bubbles, superbubbles and supergiant shells among its objects, many of them being visible for the amateur observers with common telescopes.

"McKibben and Shapley (1953) were the first to distinguish the giant stellar and gaseous groupings of the LMC, the well known Shapley constellations I - V. Later, van den Bergh named (in 1981) the constellations VI - IX. These seem to be the most active star forming areas of the LMC" (paper "Morphology and Stellar Content of Complexes in the Large Magellanic Cloud" M. Kontizas et al. 1995).




This video by ESO`s VLT is a zoom-in view of the interesting group of nebulae and OB stars  named LHa1201 N44, one of the targets you can observe with an 8-inch telescope.

This article deals with this complex which is also known as "Shapley Constellation I"  according to the LMC extended catalogue (Bica+ 1999) published in VizieR web pageN44, cataloged by Henize (1956) and named DEM2 150, 151 and 152 by Davies et al. (1976) is a luminous HII complex in LMC. It contains an assortment of compact HII regions, filaments, and shells of all sizes, as well as three OB associations3, LH447, 48, and 49 (Lucke & Hodge 1970)N44 is dominated by a prominent shell around LH47 in the central region (Chu & Mac Low 1990), paper "The Multi-Phase Medium in the Interstellar Complex N44" by Sungeun Kim et. al. 1998Situated at RA 05 22 06.9 Dec -67 56 46, N44 lies (see Figure 1) about 43 arc minutes southwest of a curious structure named "Sextant" (see the article "An enigmatic Structure in the Local Universe - part 2" in this blog).

The observation was made from Uspallata valley, in Los Andes mountains, where the dark skies make possible to carry out this kind of projects.

Figure 1. Position of the complex N44 in LMC. North is up.
Two main hazy regions are visible in the field of view at a first observation at 48x. I call them "northern region" and "southern region" (see Figure 4). The northern region is bigger than the other one but both look pretty similar in the sense that they show several faint stars embedded in nebulae structures. I identified this complex after recognize the T-shaped asterism formed by the stars HD 35862, GSC-9162-0453, HD 35978, and GSC-9162-0321 (visual magnitudes 9.3, 11.4, 9.7, and 11.4 respectively). The brightest star in the field of view is the 8.5 magnitude HD 35665. According with data given by the aforementioned catalogue (Bica 1999) the center of Shapley Constellation I lies at the center of the bigger region (indicated with the blue arrow in Figure 4). This aggregate has an overall dimension of 23 x 16 arc min and an angular position of 150° according with the same source (See Figure 2).

Matching with what can see on the DSS image (Figure 4), the area labelled with an ellipse is where nebulosity and stars are visible at this power. That is the area of the association LH49 and the HII region IC 2128 (also N44D). I found discrepances about the nature of IC 2128. Some sources (e.g. SIMBAD Database) state that is an HII region while others (like the revised NGC/IC catalogue and STScI DSS) say it is a stellar association. Beyond that differences, it is not a conspicuous object at all. The section easier to detect (a little better using of course averted vision) is the more contrasted patch on DSS image in Figure 4 immediately southwest of the 9.7 magnitude star HD 35978, appearing as a faint and defocused star engulfed, in turn, by very subtle nebulosity. Averted vision is necessary to get this view through an 8-inch telescope at low magnification.

Figure 2. According with the LMC extended catalogue (Bica 1999)
Shapley constellation I is a 23x16 arc minutes wide structure with
an angular position of 150 degrees. North is up. East to the left.
Moving to the northern section of the complex, N44C (also NGC 1936, IC 2127) seems to be the most prominent nebula there, looking round and small.

A little higher magnification (63x) shows very subtle nebulosity encompassing the northern half of the "T" asterism. To the northeast, very faint and challenging is the view of the small component N44E (see Figure 4). With averted vision a ghostly nebulosity is visible. For moments, 2 or 3 stars can be discerned there. We will analize that region again using higher power.

At 63x, N44C is the most contrasted nebulosity visible in the whole complex. Stasinska et al. (1986) favour radiative radiation of N44C by a central star whereas Pakull & Motch (1989) suggest that it could be a fossil, X-ray photo ionized nebula formed by a now
Figure 3. LH49 & N44D
quiescent X-ray binary system. "The bright main body of N44C has the appearance of a normal H II region, apart from its high excitation and He II emission. The east, northeast, and northwest boundaries of N44C are relatively sharp and have low [O III]/Ha, indicating the presence of an ionization front" (paper "The He II Emitting Nebula N44C in The Large Magellanic Cloud: Optical/Ultraviolet Spectroscopy of the Nebula and its Ionizing Star" Donald R. Garnett et al. 2000). The area southwest of N44C is visible with averted vision as a rather smooth hazy spot. N44B is round in shape but slightly fainter and smaller than N44C. Even fainter is another round nebulosity, DEM L 140, to the northwest of N44B. It is smaller than the other two mentioned nebulosities. The OB association LH47 contains 40 blue stars according to Lucke & Hodge (1970) and appears, through an 8-inch telescope, as several stars embedded in a faint hazy background. Roughly north of LH47 we find another section of the complex visible like an elongated faint nebulosity (N44I) where a chain of few stars, situated in the same direction of the elongation, can be visible (surely members of the association LH48).

Using UHC filter...

Figure 4. The N44 complex
The view of the small nebula southwest of the star HD 35978 improves clearly using this nebular filter, being visible even with direct vision. It looks smooth without stars present there. Fainter nebulosity is visible toward the west, part of the N44D section of the complex. The shape seems to be a kind of triangle.

Through this filter N44C is, by far, the most contrasted nebulosity. On the other hand, N44B looks a little smaller and less contrasted but easy to see however. Beyond the view of the bright patches N44C and N44B, the nebulosity connected to N44C from the southwest is the most obvious section of the bigger area when using averted vision. The whole big section is visible even with direct vision however. The nebula southwest of N44C is slightly more prominent that the small and round patch DEM L 140. A dark lane crosses the zone between N44C and N44B. It seems to be situated closer to N44B. The view of N44I and LH48 improves using this filter.

Using averted vision a small hazy spot, the zone of BSDL 1363, is visible among the subtle nebulosity right west of N44B.

N44E is, without a doubt, the faintest area of the whole complex visible through a UHC filter at this magnification. It is hard to see, visible for moments using averted vision.


Figure 5. LH48 & N44I
118x, without filter, is a good magnification to observe N44. The zone of IC 2128 and N44D is visible involving three stars situated there. At this magnification the region N44K comes to the view being visible as a round, faint, and smooth hazy spot. Averted vision is necessary to see it. The stellar association BSDL 1449 is visible with averted vision as a short and narrow hazy strip. N44C and N44B look round in shape with the first one a little more contrasted and bigger. The dark area crossing between both objects is again visible. DEM L 140 is, as aforementioned, fainter, so averted vision must be used to see it better. A star or point-like core is visible within it. A region that looks similar to DEM L 140 at this power is the one immediately northwest of N44B, maybe slightly wider and showing also a central star. LH47 is a conspicuous association in the field of view. In the bigger section, the whole stellar and nebulae structure there seems to connect to the region LH48-N44I which appears as a faint nebulosity with a few stars associated.

Figure 6
Using a UHC filter N44D is visible with direct vision. N44K can be barely glimpsed also, while averted vision makes possible to see the whole southern region better. Moving to the northern region, the patches N44C, N44B, and DEM L 140 stand out. N44C looks smooth in brightness along with its extension to the southwest that also looks smooth and fainter than N44C. The nebulosity in LH48-N44I is a little more conspicuous through this filter.

At 160x the section N44H is visible using averted vision, looking rather irregular. N44K is, undoubtely, a challenging object for an 8-inch telescope. At this magnification a hint of nebulosity seems to be present among the faint stars there. The view of N44C, N44B, and DEM L 140 along with the association LH47 is interesting. N44C and N44B appear very similar in size, with N44C slightly brighter. Different than N44C that looks smooth, N44B shows a few stars embedded there. A short observation of N44C a few days later using a 24-inch telescope at 192x showed the nebulosity labeled with the arrow in Figure 6 as a smooth "cometary tail" or fan-shaped hazy structure emerging from the bright and round structure of N44C. Another dark lane, less prominent than that between N44C and N44B, is visible between N44B and the more elusive DEM L 140. The structure surrounding LH47 and connecting to the bright spots in the northern region (i.e. Shell 1) was not visible at any magnification. Using a 24-inch (61cm) telescope the loop Shell 1 was not visible neither.



Which section is NGC 1929?


As with IC 2128, I found some discrepances about the object in the complex which is named NGC 1929. This situation is outlined in Figure 7. While sources like STSCI DSS web page
Figure 7
give the object indicated on the left panel, other good sources like SIMBAD Database indicate that NGC 1929 is the object on the right panel. An historical identification by Dreyer is the following, NGC 1929 (= GC 1135 = JH 2840, 1860 RA 05 22 02, NPD 158 03.6) is "faint, preceding of group", the latter comment presumably meaning it is the western member of a group of objects. According to the Revised NGC/IC project web site, NGC 1929 is a diffuse nebula or a supernova remnant. The ESO`s web page talks about a cluster of stars when NGC 1929 is mentioned. Have in mind these differences if you search for this object using these sources. In this article I adopted the designation DEM L 140.


The LMC, a surprising nearby galaxy to explore with your telescope from the Southern Hemisphere in spring and summer.


______________________________________________________________________________________________________


1LHa-120 N is the full name of an entry in the Henize catalogue of LMC emission nebulae. "L" refers to the Lamont-Hussey Observatory of the University of Michigan; "Ha" means the Hydrogen-alpha emission line, the key signature line used in the survey; "120" refers to the plate number (objective prism plate) for the LMC; "N" labels the object as a nebula, as distinct from a star (label "S").

2DEM is a catalogue of 357 nebulae in the Large Magellanic Cloud and 167 nebulae in the Small Magellanic Cloud that was published in 1976 by R.D. Davies, K.H. Elliot, and J. Meaburn. The LMC catalogue is DEM L and the SMC catalogue is DEM S.

3_ The concept of a stellar association was originally introduced in 1949 by V. A. Ambartsumian, who later separated them into OB and T associations (Ambartsumian 1968). Morgan, Sharpless, & Osterbrock (1952) considered as a stellar association any loose group of stars within an area where bright OB stars exist and with evidence of a common origin.

A recent definition of a stellar association (Kontizas et. al. 1999) refers to it as a single, unbound concentration of early-type luminous stars, embedded in a very young star forming region.

4_ LH is a catalogue of OB associations in the Large Magellanic Cloud compiled by Lucke & Hodge.


NGC 6438


A Distorted Galaxy Pair, or Maybe a Triplet System, can be Found in the Modest Constellation Octans, Home of the South Pole Star.

The faint constellation Octans seen from Pampa El Leoncito (San Juan, Argentina).
Photo by the author.
Octans, a constellation with 3 primary stars charted by Abbe Nicholas Louis de Lacaille in the 1750s encompasses the south pole star, Sigma Octantis, a faint 5.5 magnitude star you can glimpse with the naked eye from a dark sky site. Another object contained in this constellation is NGC 6438, discovered in 1835 by John Herschel. First, let`s try to answer the question formulated on the tittle above. Is this galactic pair the closest one to the south celestial pole? Certainly no, another interacting system (i.e. NGC 2573A & B) is situated even closer to the pole star and not too far from the southernmost NGC object, the galaxy NGC 2573 (polarissima australis). However, that pair, with a magnitude around 14, is a target out of reach for owners of an 8-inch telescope, even in 6.5 limiting magnitude skies. Thus, we could say that NGC 6438 is the southernmost interacting system to observe with a common amateur telescope (e.g. 6, 8 or 10-inch). More than that, we can consider NGC 6438 the southernmost interacting system with its components very close to each other in projection on the sky (the components of NGC 2573 are not so close, as you can see in Figure 2). Of course, you need to observe somewhere south of the Equator. Another requirement is that you will need at least a latitude that makes possible to see this object at a reasonable altitude above the horizon. Being a circumpolar object for most of the Southern Hemisphere, another advantage is that NGC 6438 is a target you can study at any time throughout the year, specially for those living south of latitude -20° where this galaxies never go too low in the sky.


Figure 1. The NGC 6438 system and its surrounding field. North is up.
Photo by STSCI DSS.
I observed this system around local midnight from a dark sky site in Uspallata Valley (central west Argentina), not far from the Aconcagua Provincial Park in Los Andes mountains). The seeing conditions that night were really good, I should say excellent, to try to see as many details as possible using an 8-inch telescope. The system under study, NGC 6438 / 6438A* (also ESO 10-1 / ESO 10-2), lies about 3° 50` from the south pole star Sigma Octantis.


Morphology of the system

NGC 6438, described in Dreyer`s catalog as "pretty bright, very gradually brighter in the middle" was also described by Shapley & Paraskevopoulos (1939) as a strange pair, probably a physical double, one spheroidal and the other belonging to the Magellanic type. A second description is given well afterward by Sérsic (1966) in which he notes the weak extension toward the north-preceding of the SO (NGC 6438) galaxy and the remarkable appearance of the irregular object (NGC 6438A) showing a nucleus and a disk of slightly smaller dimensions than the main body of the SO galaxy” (read more in the paper NGC 6438: A Triple System? C. J. Donzelli1, and M. Espíndola 1996). These researchers state that their analysis suggests that NGC 6438 is an interacting triplet, one S0 galaxy and two disk galaxies undergoing a merger, rather than a double system (E+S). In its now old paper "Southern Peculiar Galaxies II - NGC 6438" Sèrsic (1966) states that there are no radio sources coinciding with these galaxies. The Revised Data for NGC 6438 says that one of the galaxies is S0 type while the other one is a type ring B. This system appears also in the "Catalogue of Southern Peculiar Galaxies and Associations" (H. Arp, B. Madore, and W. Roberton) as AM 1806-852, in the category 2b: E+S interaction. In this sub-category an E-like galaxy is interacting with another galaxy which is classifiable as a disk or spiral galaxy. The sub-category contains some very disrupted pairs shown in the middle of the section, and spirals with long, open arms at the end.


Figure 2. The interacting system NGC 6438 (upper panel) and the fainter
components of the system NGC 2573A & B (lower panel).
Photo by STSCI DSS.
At low magnification (42x), the brightest star in the 1° field of view is the 6.5 magnitude star HD 159517, situated just on the border of the field when the galactic pair is centered on it (see Figure 1). A very subtle nebulosity is visible through this kind of telescope at low power. The fact that the system lies between some faint stars makes me think that we are observing both the system and the faint nearby stars so higher magnification is necessary to try to discern the galaxies from the surrounding field. From the beginning, I recommend covering your head with a black blanket to avoid any unwanted surrounding light, however weak it may be. Also, try to use your averted vision as help as this object is definitively faint for a telescope of this size. Observing carefully, some of those stars could be identified. Applying averted vision a small hazy patch could be glimpsed, without a doubt the brighter part of the system that, according to Svend Laustsen, Claus Madsen, and Richard M. West in their book "Exploring the Southern Sky: A Pictorial Atlas from the European Southern Observatory (ESO), lies at 110 million light-years from us.

At 78x the view improves a little, the group of stars and the galaxy itself can be identified, but it is not an easy view. The shape of the very faint and smooth nebulosity looks, for moments, irregular (maybe a suggestion of the fainter companion NGC 6438A, a type Ring B galaxy with a visual magnitude of 11.6 and a surface brightness 12.5 (mag per square arcmin) according to the Wolfgang Steinicke's Revised NGC and IC Catalog web page).

106x is a good magnification. Observing carefully and always with averted vision as help NGC 6438 appears, for moments, round and easier to see (or less hard to detect) than its elongated companion, NGC 6438A, that seems to be visible because a very faint, elongated East-West hazy structure reaches the star GSC-9527-1716, a faint 12.8 magnitude star (see upper panel on Figure 2). The whole systems look rather smooth in brightness, situated close to the chain of stars labeled with blue circles in Figure 2. All those stars could be glimpsed as very faint points of lights that night. The stars of the tight pair at one of the ends have magnitudes of 12.9 and 14. The star at the opposite end has a visual magnitude of 14.7 and it could be barely glimpsed through the 8-inch telescope, indicative of a dark, clean, and steady night for deep-sky observations.

196x was, maybe, the magnification that made it possible to see the galaxy pair more clearly, being always a challenging picture for an 8-inch. Taking advantage of the excellent seeing and very good transparency that night NGC 6438 was seen, at this power, round and with a slightly brighter core. An elongated hazy structure can be glimpsed roughly East-West as was aforementioned. Remember, an appropriate dark adaptation and the use of averted vision is a must to see this obscure target. A little worse view was obtained at even higher magnification (266x), with NGC 6438 barely glimpsed in the field of view, and with NGC 6438A not clearly identified.

A close encounter seems to take place in the Universe, not far from the southernmost point where you can aim a telescope from Earth, the south celestial pole.

_________________________________________________________________________________

* NGC 6438A is not an NGC object but it is sometimes called in that way. This is the galaxy PGC 61793.

Remote Globular Clusters



Some of these swarms of old stars are Outer-Halo members of the Large Magellanic Cloud and are far away from it in the southern sky, appearing as "isolated" objects.



The Large Magellanic Cloud and its remote globular clusters.
A conspicuous "nebulosity" shows up high in the sky as soon as it becomes dark, after sunset, on any summer day in the Southern Hemisphere. That "nebulosity", actually a nearby galaxy, the Large Magellanic Cloud (LMC), is surrounded by some faint constellations, namely Dorado, Reticulum, Hydrus, and Mensa. You can enjoy the view of these constellations from a dark sky site. Now, did you know that those constellations host globular clusters that are members of our satellite galaxy? Of course you will need a telescope, at least an 8-inch diameter mirror, to see some of them.

This article deals with 5 globular clusters that are situated far from the central bar of the Large Magellanic Cloud, thus appearing as isolated stellar systems in the southern sky, in the south celestial pole neighborhood.

From any place on planet Earth south of -31 of latitude, this five objects never set, being thus what is known in astronomy as circumpolar objects. However, the summer months in the Southern Hemisphere (i.e. December, January, and February) is the optimum season to see them at their highest.
The Large Magellanic Cloud (LMC) is unique in containing massive star clusters at all stages of evolution.  ReticulumNGC 1841, and NGC 1466, three of the objects included in this article, have at times been considered to be Milky Way globulars (e.g. Webbink 1985). Bengt E. Westerlund, in his book "The Magellanic Clouds" (1997), states that these clusters are all outside the sky-projected tidal radius, but still considered to be LMC members.


NGC 1841
R.A. 04 45 23.4  Dec. -83 59 56.6 (J2000.0)

This is an extragalactic globular cluster situated in constellation Mensa, discovered in 1836 by John Frederick William HerschelIn projection on the sky, this cluster is situated 145 south of the center of the Large Magellanic Cloud, close to the border with the southernmost constellation Octans (see map above). In fact, NGC 1841 is not too far from the south polar star Sigma (σ) Octantis (roughly 65). NGC 1841 could have been formed in a relatively isolated fragment of the proto-LMC, or it could have been part of an independent system now disrupted. Further support to the latter hypothesis could be the fact that NGC 1841 is the farthest cluster from the LMC center ( 10 kpc) (paper "The relative ages of LMC old clusters, and the case of NGC 1841" by  Ivo Saviane, Alfred Rosenberg, Giampaolo Piotto, & Antonio Aparicio, 2002)Evidence is provided that NGC 1841 is younger than the rest of LMC globular clusters.
Figure 1

I observed this remote globular cluster from a dark sky site, with a clear and steady sky that night. Although several sources give a magnitude of 14.1 for this object (which would make it a target out of reach of an 8-inch telescope), it could be glimpsed through an 8-inch telescope working at 42x like a very faint and hazy patch of light showing a smooth brightness. This supports my opinion that this cluster should be brighter than that magnitude. The value of 11.4 given by the Simbad Astronomical Database  seems to be much more accurate. It is visible through an 8-inch (20cm.) telescope according with Ernst Johannes Hartung`s book "Astronomical Objects for Southern Telescopes: With an Addendum for Northern observatories". Averted vision slightly improves the detection of it at low magnification. The star HD 34017 (visual magnitude 9.1, spectral type F3V) is, along with HD 31132 (magnitude 8.8), one of the brightest stars in the 1◦ degree field of view. I used HD 34017 and the patterns of stars encircled with blue ellipses as guides to find the exact place where NGC 1841 lies (Figure 1).

At 78x, NGC 1841 appears in the field of view relatively big, round, faint, and smooth in brightness. As with lower magnification, averted vision helps for a better detection of this elusive object for an 8-inch telescope. It was not possible to resolve the cluster in some of its members.


John Frederick William Herschel
106x is a good power to observe this cluster. It looks pretty big, faint, and smooth without resolved members. Even higher magnification (148x) makes the view of NGC 1841 not very good, appearing very faint and being difficult to see because of the low contrast. Optimum Detection Methods give, if we consider a visual magnitude of 11.4 and angular dimension of 0.9x0.9 arc min for this cluster, an optimum magnification of 80x under a 6.3 or 6.4 limiting magnitude sky, and 75x under a 6.5 sky.

Remember, beyond all the theory and methods for improving the detection of any deep sky object, the best you can do is to go to the mountains, or a place with dark skies, and have your own experience observing the targets in your observing programs. It is observing how you can draw your own conclusions about how difficult is to detect an object through the telescope that you have. But do not stop there, try to observe the same object in different nights, so you can compare the results. Every observing night is a unique experience that enriches your passion for stargazing.


Reticulum cluster
R.A. 04 36 09.0 Dec. -58 51 30.0 (J2000.0)


Figure 2. Position of the Reticulum Cluster in the sky
In 1974, Sèrsic discovered an object in constellation Reticulum on plates taken with the 0.7m Maksutov telescope at Cerro El Roble Observatory. At first, he catalogued it as a probable dwarf galaxy and member of the Local Group. More recently, Demers & Kunkel (1976), and Gratton y Ortolani (1987) suggest that "Reticulum system" is a globular cluster of the Large Magellanic Cloud. Reticulum is an old and sparsely populated globular cluster that is located ≈ 11◦ from the center of the LMC (Demers & Kunkel 1976). Paper "Variable Stars in Large Magellanic Cloud Globular Clusters III: Reticulum" by Charles A. Kuehn et. al. 2013. Reticulum is classified as an OoI type1 cluster (Oosterhoff classification). It is located at approximately 11◦ from the LMC bar (l =269◦ , b=-40◦).

This cluster resides in constellation Reticulum, very close to the border with Dorado (see Figure 2. Enlarge for a more detailed view). A way to find it is to use the stars Alpha (α) ReticuliAlpha (α) Doradus, and Zeta Doradus that form a triangulum in the sky. The cluster lies roughly in the spot where bisectors of that triangle cross each other.




Figure 3
Once there, I observed the field at low magnification, knowing in advance that this is a faint globular for this kind of telescope. After identifying the star GSC-8515-1355 (magnitude 12) and the pair TYC 8515-1611-1 and GSC-8515-0765 (visual magnitudes 10.7 and 11.8 respectively) I focused on the small region between that stars (center of the field of view on Figure 3) to try to glimpse this extragalactic globular. Only a few faint stars are visible there at this magnification, surely foreground stars of our Milky Way galaxy.

At higher magnification (63x), the view is similar. The same stars are visible (labelled with blue circles in Figure 3). Even higher power (118x) did not show more than that faint stars scattered in the area. The faint star labelled with a red circle could be very barely glimpsed using averted vision at this last magnification.

As a final remark, this globular cluster is a faint object for 8-inch telescope. Owners of bigger mirrors should be glimpse this member of the Large Magellanic Cloud when observing from a dark sky site.






ESO 121-SC03
R.A. 06 02 02.50 Dec. -60 31 25.5 (J2000.0)

ESO 121-SC03. Picture from AladinLite view
ESO 121-SC03 lies at a projected angular separation of ∼ 10◦ from the LMC centre. It was first studied in detail by Mateo et. al. (1986). David Stevenson in his book "The Complex Lives of Star Clusters" (2015) estimates the age of this globular in around 9 billions years.

At 42x, the field where this object, also known as KMHK2 1591, is situated looks interesting with some stars forming fine shapes. The brightest star in the 1◦ field of view is the 6.4 magnitude SW Pictoris. The chain of four stars (indicated with blue lines in Figure 4), which contains the 6.9 magnitude star HD 41451 at its eastern end, and the stars forming a sort of crown (center of the field in Figure 4) helped to find the zone where this faint and obscure member of the Large Magellanic Cloud lies. This 14 magnitude cluster with angular dimension 2.0 x 2.0 arc minutes is, without a doubt, a faint object for an 8-inch telescope. Obviously at this low magnification nothing was visible in the field.


Figure 4
According with the paper "Photometry of Magellanic Cloud clusters with the Advanced Camera for Surveys - II. The unique LMC cluster ESO 121-SC03" by A. D. Mackey et al. (2006), this cluster may lie 20 per cent closer to us than does the centre of the LMC.

At 78x, ESO 121-SC03 is not visible after observing carefully under a dark and steady sky. I observed it again from another place, higher in Los Andes mountains, but I had the same results after using 118x. In both nights and from both sites, something seems to be there when observing with averted vision, but it is hard to assure that the cluster can be glimpsed. As I always say, if you are not sure you saw any object, you must say "I did not see it"

The brightness of this extragalactic object reserves the view only for bigger instruments. Higher magnification (e.g. 160x, 222x) gave the same results, no object visible in the field.









NGC 1466
R.A. 03 44 32.4 Dec. -71 40 16 (J2000.0)

Figure 5
John Frederick William Herschel discovered NGC 1466 in 1834, a globular cluster with a magnitude of 11.4 situated in constellation Hydrus. It is listed, along with NGC 1841, 2257, and Reticulum, as one of the oldest generation globular (10 Gyr) in our nearby galaxy according to B. E. Westerlund in his book "The Magellanic Clouds" (Cambridge University Press, 1997)

With roughly 8◦ of separation with the Large Magellanic Cloud in the sky, this member of our satellite galaxy is visible at 42x in a field that offers a beautiful image. The 6.3 magnitude HD 24188 is, by far, the brightest star in the 1◦ field, visible close to the cluster. This makes easy to find NGC 1466. At this low power, NGC 1466 looks like a slightly defocused star situated between the stars HD 24115 (visual magnitude 9) and the fainter GSC-9156-0534 (visual magnitude 12). At this magnification, the globular cluster reminds me a round planetary nebula. With averted vision, the core of NGC 1466 appears somewhat brighter.

NGC 1466. ESO Online DSS


At 78x it is possible to get a good view of the cluster and the stars surrounding it. NGC 1466 appears obvious in the field of view of the telescope. Even with direct vision the cluster shows some "granularity". Applying averted vision, at least two stars can be discerned.

106x seems to be a good magnification to observe NGC 1466, appearing very clear in the field of view as a round hazy patch. Some members of this cluster are easily discerned.

Even higher magnification, like 148x, is a good power to see this cluster under a very dark sky. You can see a nebulous patch and some stars within when using averted vision..


NGC 2257
R.A. 06 30 13.86 Dec. -64 19 32.2 (J2000.0)

Figure 6
NGC 2257 (also ESO 87-24, KMHK 1756) was discovered in 1834 by John Frederick William Herschel. NGC 2257 appears of particular interest since according to Stryker 1983, Nemec Hesser and Ugarte 1985 (NHU) and Walker 1989 (W89) it is probably the oldest LMC cluster. This object is situated about 8◦5 northeast of the LMC bar in projection on the sky.

I observed this LMC cluster when it was about 59 in the sky, just a few minutes after its transit by the local meridian, so that the altitude was the best to try to catch this old member of our satellite galaxy. At 48x, I could identify an asterism which I indicate with lines in Figure 6. This asterism was very userful to focus the atention on the spot where NGC 2257 should appear. This cluster can be glimpsed at this magnification, appearing as a very faint, round, and smooth patch of light immediately to the West of the stars TYC 8902-1763-1 and GSC-8902-0650 (visual magnitudes 10.9 and 12.4 respectively). Averted vision sligthly improves the view of it.

At 63x the view of the cluster is similar to that at lower power. Without a doubt, a "nebulosity" with smooth brightness and without any discerned star can be seen in the field. It looks round in shape. It is a faint object (magnitude 12.6) so averted vision helps for a little sharper image of the cluster against the starry field.


Figure 7
118x shows this object faint, a ghostly image of a globular cluster. Even with averted vision the view is hard and elusive. No stars are discerned in the cluster at this power. The angular dimension of NGC 2257 looks similar to the distance between the aforementioned stars TYC 8902-1763-1 and GSC 8902-0650 (see Figure 7).

There were not better results applying higher magnification (namely 222x). Again, a faint and featureless image of the cluster showed up in the eyepiece field. Even if NGC 2257 is visible through an 8-inch telescope, the view through bigger scopes should be more interesting and fruitful.






“Astronomy, as nothing else can do, teaches men humility.”
Arthur C. Clarke (1917-2008)




_______________________________________________________________________________________________


1_ The Dutch astronomer Pieter Oosterhoff noticed that there appear to be two populations of globular clusters, which became known as Oosterhoff groups. The second group has a slightly longer period of RR Lyrae variable stars.[39] Both groups have weak lines of metallic elements. But the lines in the stars of Oosterhoff type I (OoI) cluster are not quite as weak as those in type II (OoII).[39] Hence type I are referred to as "metal-rich" (e.g. Terzan 7[40]) while type II are "metal-poor" (e.g.ESO 280-SC06[41]).

2_ KMHK refers to a list of LMC clusters published in 1990 by M. Kontizas, D.H. Morgan, D. Hatzidimitriou and E. Kontizas (Astronomy and Astrophysics Suppl. Series, Vol. 84, p. 257).
